Description

Honeywell Midas Sensor Cartridge - Nitrogen Trifluoride (NF3 )0-40ppm*, Methyl Fluoride (CH3F) 0-120ppm **

**Requires MIDAS-T-HTP Pyrolyzer, * (MIDAS-T-00P) must also be ordered.

Require Install, Commissioning, Calibration or Servicing?

Safety Gear Store are able to install, commission and service your fixed gas detection system. We offer a professional service from fully trained, certified and manufacturer approved engineers, we are also one of the only suppliers with engineers that carry spares in their vehicles to ensure a quick and efficient service that will enable you to continue using your facility.

For more information on what we offer please visit one of the below pages:

Fixed Gas Detection System Install and Commissioning

Fixed Gas Detection System Calibration and Servicing

Gas Measured:	Nitrogen Trifluoride (NF3)
Part No.:	MIDAS-S-XHF
Sensor Technology:	3 electrode electrochemical cell
Measuring Range (ppm):	NF3 0 - 40 ppm
Minimum Alarm 1 Set Point:	4.0ppm
Repeatability:	< ± 10% of measured value
Linearity:	< ± 20% of measured value
Response Time:	< 110 seconds
Sensor Cartridge Life Expectancy:	≥ 24 months under typical application conditions
Operating Temperature: Effect of Temperature Zero Sensitivity	0°C to +40°C (32°F to 104°F) < ± 0.002ppm / °C (at 0°C to 20°C) < ± 0.008ppm / °C (at 20°C to 40°C) < ± 0.4% of measured value / °C
Operating Humidity (continuous): Effect of Humidity Zero Sensitivity	20 – 75% rH ‎ < ± 0.003ppm / % rH < ± 1% of measured value / % rH
Operating Pressure:	90 – 110kPa
Effect of Position:	No effect in typical application
Long Term Drift Zero Sensitivity	‎ No drift < 15% of measured value / year
Calibration Gas:	Hydrogen Fluoride (HF)
Challenge Gas (Bump Test):	Chlorine (CL2)
Warm Up Time:	< 20 minutes
Storage Temperature	+5°C to +25°C (+41°F to +77°F

Midas Nitrogen Trifluoride and Methyl Fluoride Sensor Cartridge Spec Sheet

Products specifications

Attribute name	Attribute value
Gases Detected	Nitrogen Trifluoride (NF3), Methyl Fluoride (CH3F)

Honeywell Midas Sensor Cartridge - Nitrogen Trifluoride (NF3 )0-40ppm*, Methyl Fluoride (CH3F) 0-120ppm **

Nitrogen Trifluoride (NF3 ) Methyl Fluoride (CH3F)

Manufacturer: Honeywell

SKU: MIDAS-S-XHF

£180.00 excl vat £216.00 inc vat
