Description

Honeywell Midas Sensor Cartridges - Boron Trifluoride (BF3) 0.72-8 ppm, Hydrogen Fluoride (HF) 1.05-12 ppm, Nitrogen Trifluoride (NF3)* 3.6-40 ppm Tungsten Hexafluoride (WF6) 1.05-12 ppm

(MIDAS-T-00P) must also be ordered.

Require Install, Commissioning, Calibration or Servicing?

Safety Gear Store are able to install, commission and service your fixed gas detection system. We offer a professional service from fully trained, certified and manufacturer approved engineers, we are also one of the only suppliers with engineers that carry spares in their vehicles to ensure a quick and efficient service that will enable you to continue using your facility.
For more information on what we offer please visit one of the below pages:

Fixed Gas Detection System Install and Commissioning

Fixed Gas Detection System Calibration and Servicing

Gas Measured:	Nitrogen Flouride (NF3)
Part No.:	MIDAS-S-HFX 1 year standard warranty MIDAS-E-HFX 2 year extended warranty
Sensor Technology:	3 electrode electrochemical cell
Measuring Range (ppm):	HF 0 - 12 ppm
Minimum Alarm 1 Set Point:	1.5ppm
Repeatability:	< ± 10% of measured value
Linearity:	< ± 10% of measured value
Response Time:	< 30 seconds
Sensor Cartridge Life Expectancy:	≥ 24 months under typical application conditions
Operating Temperature: Effect of Temperature Zero Sensitivity	0°C to +40°C (32°F to 104°F) < ± 0.002ppm / °C (at 0°C to 20°C) < ± 0.008ppm / °C (at 20°C to 40°C) < ± 0.4% of measured value / °C
Operating Humidity:	20 – 75% rH
Operating Pressure:	90 – 110kPa
Effect of Position:	No effect in typical application
Calibration Gas:	Hydrogen Fluroide (HF)
Challenge Gas (Bump Test):	Chlorine (Cl2)
Warm Up Time:	< 20 minutes
Storage Temperature:	+5°C to +25°C (+41°F to +77°F)

Other Detectable Gases
The following additional gases can be detected with this sensor cartridge. Sensor performance and characteristics will be representative of the data as tabulated above. Consult the Technical Manual to set up the Midas® transmitter with the designated identification code for each of the following gas types.

Detectable Gas	Chemical Formula	Measuring Range
Tungston Hexaflouride	WF6	0-12ppm
Boron Triflouride	BF3	0-8ppm
Nitrogen Triflouride	NF3	0-40ppm

Midas Mineral Acids (HF Group) Sensor Cartridge Spec Sheet

Products specifications

Attribute name	Attribute value
Gases Detected	Boron Trifluoride (BF3), Hydrogen Fluoride (HF), Tungsten Hexafluoride (WF6), Nitrogen Trifluoride (NF3)

Honeywell Midas Sensor Cartridges - Boron Trifluoride (BF3) 0.72-8 ppm, Hydrogen Fluoride (HF) 1.05-12 ppm, Nitrogen Trifluoride (NF3)* 3.6-40 ppm Tungsten Hexafluoride (WF6) 1.05-12 ppm

Detects 4 different types of gas Boron Trifluoride (BF3) 0.72-8 ppm, Hydrogen Fluoride (HF) 1.05-12 ppm, Nitrogen Trifluoride (NF3)* 3.6-40 ppm Tungsten Hexafluoride (WF6) 1.05-12 ppm

Manufacturer: Honeywell

SKU: MIDAS-E-HFX

£273.00 excl vat £327.60 inc vat

Qty:

Honeywell Midas Sensor Cartridges - Boron Trifluoride (BF3) 0.72-8 ppm, Hydrogen Fluoride (HF) 1.05-12 ppm, Nitrogen Trifluoride (NF3)* 3.6-40 ppm Tungsten Hexafluoride (WF6) 1.05-12 ppm

£273.00 excl vat £327.60 inc vat

Qty:
