BW DX-BWC4 IntelliDoX Automatic Instrument Management System

The above IntelliDox is for the BW BWC4 (please see options for MicroClip Series) One Enabler kit is required for each stand-alone IntelliDox module or gang of up to 5 connected modules. IntelliDoX is an instrument management system for the BW BWC4 gas detector. It combines smart docking modules with our Fleet Manager II software to make the BW BWC4 the most flexible, configurable maintenance-free device on the market.

It does the quickest bump test in the industry as you can bump a BW BWC4 detector in less than 10 seconds. Simply place the BW BWC4 in the docking module, and it automatically tests the gas detector and sensors while transferring data to your computer for easy record-keeping. The BW BWC4 is maintenance-free and easily allows you to customise it. With IntelliDoX, you can configure the alarm set points and other parameters based on your changing requirements. So your BW BWC4 always works the way you want it to — whether you’re doing a turnaround or going from one site to another.

The IntelliDoX system is also easy to set up: It takes just two minutes, and all you need is an Ethernet cable or a USB drive. You can feel more confident than ever in the reliability of your gas detection — while improving safety, compliance and productivity.

IntelliDox Features

Bump testing, configuration, and record-keeping support for the BW BWC4. User updatable settings:

• Configure Alarm Settings
• Display Gas Reading During Alarm
• Enable Non-compliance Indicator
• Hibernate Detector
• Schedule Bump Reminders
• Transfer Event Logs
• Time Display Preferences
• Update Firmware
• Industry-leading FastBump test that eliminates bottlenecks, while avoiding costly purge cycles that waste gas
• Gangable up to five modules, each with its own LCD screen and keypad for independent operation
• Easy to set up with no tools required
• Easy to connect via Ethernet to a Network
• USB port to easily configure dock module settings or retrieve data without network access
• Enables endless configuration of BW BWC4 alarm set points and other parameters throughout the gas detector operation life



Box Contents of IntelliDoX Docking Module

Each IntelliDoX Docking Module package contains:

• One IntelliDoX module with a factory-installed nest for acompatible portable gas detector
• Integrated retractable stand / wall mount
• One printed Quick Reference Guide
• One CD containing the IntelliDoX Operator’s Manual in PDF format
• One CD containing Fleet Manager II software, version 4.x or higher



(The power adapter, power cord, calibration gas tubing, exhaust tubing, and user manual are packaged separately as the IntelliDoX Enabler Kit)

If the IntelliDoX module is damaged or if parts are missing, contact Safety Gear Store immediately

IntelliDoX Enabler Kit

(One Enabler Kit is required for each stand-alone IntelliDoX module or gang of up to 5 connected modules)

Each IntelliDoX Enabler Kit package contains:

• One power supply and AC power cord appropriate to shipping destination
• One IntelliDoX end plate
• One ethernet cable
• Calibration gas cylinder tubing and purge gas tubing, 4.6 meters (15 feet)
• Quick connect fittings
• Inlet filters
• Assorted connectors
• One printed Quick Reference Guide
• One CD containing the IntelliDoX Operator Manual in PDFformat
• One CD containing Fleet Manager II software



If Enabler Kit parts are damaged or missing, or if additional Enabler Kits are required, contact Safety Gear Store immediately.
