Sample System " Searchpoint Optima (ATEX M25)" for integration of one sensor mounted in series, Type Optima Plus consisting of: - housing 600 x 400 x 260 mm, sheet metal, covered - injector Typ. 710200 incl. throttle check valve fitting - 1x sample gas filter AGF-FE-4-KV incl. mounting bracket and filter element FE-E4 - 1x flow meter, type DK800 with needle valve and inductive ring sensor TG15, monostable, P P - bypass-connector for system extension - completely tubed in PTFE - suitable to use in hazardous area zone 2 Please note the Optima Plus device, the calibration and the junction box need to be ordered separately. Also do not forget the flow controller and the motor protection switch if needed.

Flame Detectors

Touchpoint Plus Controller - TPPLBDWV8S4NNRN - Touchpoint Plus Controller / Touchpoint Plus base control unit for up to 8 channels / DC supply / Wall mounted enclosure / 8 x mV inputs / 2 programmable relays / 4 x repeated mA outputs / Without battery backup / Future option / With Modbus TCP + Webmonitoring

Touchpoint Plus Controller - TPPLBDWV8S4NNTN - Touchpoint Plus Controller / Touchpoint Plus base control unit for up to 8 channels / DC supply / Wall mounted enclosure / 8 x mV inputs / 2 programmable relays / 4 x repeated mA outputs / Without battery backup / Future option / With Modbus TCP

Touchpoint Plus Controller - TPPLBDWV8S4NRNN - Touchpoint Plus Controller / Touchpoint Plus base control unit for up to 8 channels / DC supply / Wall mounted enclosure / 8 x mV inputs / 2 programmable relays / 4 x repeated mA outputs / Without battery backup / With RS485 Modbus RTU / Future option

Touchpoint Plus Controller - TPPLBDWV8S4NNRN - Touchpoint Plus Controller / Touchpoint Plus base control unit for up to 8 channels / DC supply / Wall mounted enclosure / 8 x mV inputs / 2 programmable relays / 4 x repeated mA outputs / Without battery backup / Future option / With Modbus TCP + Webmonitoring
