Crowcon Flamgard Plus

Require Install, Commissioning, Calibration or Servicing?

Safety Gear Store are able to install, commission and service your fixed gas detection system. We offer a professional service from fully trained, certified and manufacturer approved engineers, we are also one of the only suppliers with engineers that carry spares in their vehicles to ensure a quick and efficient service that will enable you to continue using your facility.
For more information on what we offer please visit one of the below pages:

Fixed Gas Detection System Install and Commissioning

Fixed Gas Detection System Calibration and Servicing

The product featured is:

Overview

Flamgard Plus is a Flameproof (Exd) flammable gas detector which uses poison-resistant pellistors to detect explosive levels of hydrocarbons, hydrogen and other flammable gases and vapours, including aviation fuel and leaded petrol vapours.

Local and convenient calibration

• Calibration can be performed locally without the need for hot work permits
• Local display and buttons enable calibration without opening the junction box



Flexible outputs

• 4-20mA current sink or source – works with a wide selection of control panels
• 3 wire format
• Optional relays for alarm and fault – can be used for switching local alarms



Rugged and reliable

• Constructed using marine-grade aluminium with a stainless steel sensor housing – proven track record for operation in the harshest environments
• Ingress protection to IP65 as standard



Wide range of sensors

• Choice of catalytic beads for a wide selection of flammable gases and vapours – gas detector tailored to your requirements



Gases & Ranges:

Data Sheet

Accessories:

Below is a small selection of the accessories available for the Flamgard Plus.

Spray deflector - C01052 - For use outdoor installations and to protect from water sprays, for example in water treatment or food processing plants. For extremely wet environments eg: offshore installations, use weatherproof cap, CO1442, instead.

Weatherproof cap - C01442 - For offshore or other extremely wet environments in place of spray deflector.

Collector cone - C01051 - For aiding detection of light gases such as methane. 38cm/15″ Dia. Includes accessory adaptor.

Stainless steel flow adaptor - C016188 - For use where a gas sample is being piped to the detector. For 96HD type sensors.

Self adhesive carbon cloth filter - C01254 - Removes long chain hydrocarbons where these can be a problem.

Exd Cable Gland Adaptors - ATEX certified Exd cable gland adaptors.

Exd/Exe Certified Brass Cable gland - M02354 - Suitable for Steel Wire Armoured cables with outside diameter 15.5mm to 21.1mm (inner sheath 6.7mm to 14mm). Certified to ATEX (ll 2DG, Exd llC/Exe ll), IECEx, CSA, GOST-R and NEPSI standards. M20 x 1.5mm thread. Ingress protection to IP66/67/68.

Calibration adaptor - C03005 - To enable calibration gas to be applied to the detector. One adaptor can be used for several detectors.
